What’s mean for Through Hole (THT) PCB Assembly and Surface Mount Technology（SMT）PCB Assembly ? <br> <br> [email protected] <br> <br>Surface Mount Technology (SMT) is necessary for PCB assembly. If the PCB has no through-hole components, Through Hole (THT) PCB Assembly is not needed. <br> <br>SMT assembly: SMT stands for surface mount technology, which is a versatile PCB assembly technology. Currently, all electronic components can be made into surface-mounted devices (SMD). SMDs are interconnected to the PCB pads with solder paste. SMT assembly is automatic. <br> <br>THT assembly: THT, or PTH or DIP, means through-hole technology. The electronic components that require THT assembly have long pins. Usually, they are capacitors, fuses, and connectors. The PCB is pre-drilled, and these components&#039; pins plug in the holes and wave reflowed. THT assembly is manual. <br> <br>In the PCB assembly process, SMT assembly happens before the THT assembly. <br> <br>DIP PCB Assembly <br> <br> <br> <br>What are the benefits of Through Hole PCB assembly? <br> <br>Through-Hole PCB Assembly comes with a range of benefits including: <br> <br>Withstanding stress-As opposed to SMT components, through-hole components are known for their ability to withstand mechanical and environmental stress. <br> <br>Perfect for large components-Through-hole works well for large components that have to undergo high power and high voltage <br> <br>High heat tolerance-Known for their high heat tolerance, they find application in a number of industries, particularly military and aerospace. <br> <br>Ease of Prototyping- Through-hole PCBs also lend themselves to ease of prototyping and improved reliability <br> <br>High Reliability-Through-hole PCBs are best used for high-reliability products that require stronger connections between layers. <br> <br> <br> <br>Little surprise then, that even though surface mount components allow for denser configurations, for larger and heavier components that require strong bonds, through-hole technology has remained resilient and relevant. <br> <br> <br> <br>What are the capabilities you offer for Through Hole PCB assembly? <br> <br> <br> <br>We provide through-hole PCB services to a variety of industries including medical, electronics, instrumentation, and military, all thanks to our complete assembly capabilities: <br> <br>• Hand soldering <br> <br>• Dual wave flow solder <br> <br>• Hand Insertion of components <br> <br>• Automate axial or radial insertion <br> <br>• RoHS soldering using tin-lead solder <br> <br>• Use of high and low melting point solder <br> <br>• Prototype build to high-volume assembly <br> <br>• Functional test and automated inspection <br> <br>• Support various types of PCBs including metal core PCBs, Rigid PCBs, Flex-rigid PCBs, FR4 PCBs, etc. <br> <br> <br> <br> <br>THT PCB Assembly <br> <br> <br> <br> <br> <br>Disadvantages of Through Hole Assembly <br> <br>Like any other manufacturing or assembling techniques, Through Hole PCB Assembly has its disadvantages too. <br> <br> <br> <br>These include: <br> <br>Longer production time-It takes a lot of time to drill the multiple holes through which the leads are expected to run. <br> <br>Expensive-because the drilling process is difficult and time-consuming, it increases the cost of production <br> <br>Minimizes space on the boards-drilling the holes on the surface of the board limits the routing area for tracing signals. <br> <br>Also, by feeding the leads through the board, only one of its sides is usable, thus making the THT PCB a bit slower in operation speeds. <br> <br>Through Hole Assembly Components – What are the Best Components for Through Hole Assembly? <br> <br> <br> <br>Radial lead components <br> <br>Axial lead components. <br> <br> <br> <br>Types of Through Hole PCB Assembly <br> <br>There are two (2) main types of the Through Hole PCB Assembly. The first is the Automated Through Hole PCB Assembly. The second is the Manual Through Hole PCB Assembly. <br> <br> <br> <br>On the one hand, the automated variant is roundly touted to be faster and cost-effective because it takes little time to be completed. It also demands little human inputs, which makes it cost-effective. <br> <br> <br> <br>On the other hand, the manual Through Hole PCB Assembly involves the traditional or manually-operational model of drilling the holes into the Printed Circuit Boards (PCBs). This model tends to take time and attracts more costs. <br> <br> <br> <br>Functional tests and automated inspection for Through Hole PCB Assembly <br> <br>Using automated inspection is very critical in minimizing turnaround time to ensure timely delivery of the boards. <br> <br> <br> <br>Conclusion <br> <br>As you can see, Through Hole Assembly of PCB can be time consuming. <br> <br>However, in some applications, it is worth it more so when mounting heavier and bulkier components. <br> <br>You can easily achieve the strength by soldering the components on the reverse side as you have seen. <br> <br>In fact, it is virtually impossible to pull components assembled using Through Hole Assembly. <br> <br>The good news, today’s guide has simplified the Through Hole PCB Assembly technique. <br> <br> <br> <br>Do you have questions or inquiries on Through Hole Assembly process? <br> <br>Contact us now. [email protected] <br> <br> <br> <br> <br> <br>ICT Testing for PCBA <br> <br>ICT Testing for PCBA <br> <br> <br> <br>In addition to through hole PCB assembly, we also provide value-added services, such as conformal coating, labeling, and complete PCB encapsulation. <br> <br> <br> <br>Through-hole PCB Assembly Testing and Inspection at Hitechpcba <br> <br>In-Circuit Testing: <br> <br>This type of testing is conducted for high volume production lines, and helps us check every minute soldering and other components in detail. <br> <br>Automated Optical Inspection: Abbreviated as AOI, these tests are performed to ensure that product is free from soldering, component, and BGA defects. <br> <br>Automated X-Ray Inspection(AXI): <br> <br>This testing is performed to inspect insufficient fills, short circuits, fills, etc. The automated X-ray inspection helps reduce the number of defects and improve the quality of the Through-Hole circuit. <br> <br>Burn-in Tests: <br> <br>These tests detect components’ failure or reliability in real environments. <br> <br>Assisted Visual Inspection: <br> <br>Our experts use a wide range of advanced visual inspection equipment to perform a detailed inspection of soldering and component placement accuracy. <br> <br>Through Hole PCB Assembly <br> <br>What’s difference between SMT assembly and THT assembly? <br> <br> <br> <br>Most contract PCB Assembly manufacturers concentrate on their surface mount technology capabilities for PCB assembly. The SMT lines can be almost completely automated making it possible to run a high volume of boards with little human intervention and a low cost per board. Through whole assembly whether automated or manual is a slower process, it takes resources away from the high-volume business that many manufacturers prefer. <br> <br> <br> <br>Only about 10 percent of the parts we buy are through-hole. Nearly 75 percent of the boards we run are mixed technology, which is a combination of through-hole and SMT parts one reason for this is that nearly half of our board assemblies are for high powered boards which use capacitors inductors and transformers to transfer energy. The size of these components is proportional to the energy they can store so for a high-power board we need to use some fairly large and heavy components and that means through-hole technology, in addition things like customer accessible connectors, that have to withstand stress as cables are connected and removed are likely to be through-hole components. Through-hole components are held in place by the pins as well as the solder so you can get a much stronger and more reliable mechanical bond than with surface mount components that have only solder to hold them in place. If a contract manufacturer is focused on higher volume SMT business, it&#039;s important to understand how they will handle through-hole components when you need them at z-axis. We run mixed technology boards every day we have a modern stuff line with a paperless process for assembly instructions and assemble in a single piece flow from the stuff line to a wave solder to inline inspection, d-paneling, qc testing. <br> <br> <br> <br>In addition to PCB Assembly, be it through hole or surface mount, at Hitech Circuits Co., Limited we also undertake PCB assembly rework offering complete reliability, high quality and optimal costs. Not only are we well-versed in inventory management, fabrication and process control, we also have a stringent control on vendor component management.

Hitechpcba is a wоrld-lеаding PCB Manufacturing &amp; PCB Assembly company with more than 20 years experience in the electronics manufacturing industry. We focus on PCB Design, PCB Layout, Circuit board fabrication, Turnkey PCB assembly, and electronic parts sourcing services. <br> <br>[email protected] <br> <br>With mature supply chain, talented design team, advanced manufacturing techniques and quality control systems, Hitechpcba is able to provide one-stop electronics manufacturing services and solution for our customers to help them stand out in the marketplace. <br> <br>We offer a full range of Electronic manufacturing services.

What is Rogers PCB? <br> <br>[email protected] <br> <br>Rogers PCB is a type of printed circuit board (PCB) material made from a combination of epoxy and ceramic. It is well known for its high dielectric constant, low loss tangent, and high thermal conductivity, making it an ideal material for high-frequency applications. It is used in a wide range of electronics, such as: <br> <br>5G Station <br> <br>Cellular Base Station Antennas and Power Amplifiers <br> <br>Automotive Radar and Sensors <br> <br>Microwave point to point (P2P) links <br> <br>LNB’s for Direct Broadcast Satellites <br> <br>Microwave equipment of all kinds. <br> <br>RF Identification (RFID) Tags <br> <br> <br>Rogers PCB is produced using the raw materials of the Rogers Company. Rogers company manufactures the laminate materials that are often used for manufacturing circuit boards. The Rogers PCB is a type of high-frequency PCB board, quite different from the traditional PCB board materials, epoxy resin. It uses the ceramic base as the material of high frequency. The major advantage of Rogers PCB is the temperature stability and superior dielectric constant.

Hitechpcba is a wоrld-lеаding PCB Manufacturing &amp; PCB Assembly company with more than 20 years experience in the electronics manufacturing industry. We focus on PCB Design, PCB Layout, Circuit board fabrication, Turnkey PCB assembly, and electronic parts sourcing services. <br> <br>[email protected] <br> <br>With mature supply chain, talented design team, advanced manufacturing techniques and quality control systems, Hitechpcba is able to provide one-stop electronics manufacturing services and solution for our customers to help them stand out in the marketplace. <br> <br>We offer a full range of Electronic manufacturing services.

The HDI board is based on the traditional double panel as the core board, which is made by continuously accumulating. This circuit board made by a continuous layer is also called the Build-Up Multilayer (BUM). Compared with the traditional circuit board, the HDI circuit board has the advantages of &quot;light, thin, short, small&quot;. <br> <br> <br> <br>The electrical connection between HDI&#039;s plate layer is achieved by conductive pores, buried holes, and blind holes. Its structure is different from ordinary multi -layer circuit boards. A large number of blind holes are used in HDI boards. HDI PCB uses laser direct drilling, and standard PCB usually uses mechanical drilling, so the number of layers and high width ratio often decreases.

What is a prototype PCB assembly? <br> <br>PCB prototyping is the experimentation pilot stage of the product which is to be mass produced at a later stage. This is more of an experiment which is done after the initial discussions and the design. This offers a pre-production analysis of the boards that are to be manufactured, reducing the possible number of errors in the PCB design. PCB prototypes help the manufacturer analyze the strengths as well as weak areas of their proposed circuit boards. Prototypes also serve as a reference point for future versions of the same product. At Hitechpcba, we handle PCB prototype assembly in quantities from one to hundred printed circuit boards. <br> <br>We have acquired capabilities that enable us to serve our clients better. All these years, we have worked on many complex prototype PCB assembly projects, and we believe the following capabilities have helped us serve our clients better. <br> <br>Prototype PCB Assembly Services: We specialize in the following prototype printed circuit board assembly services. <br> <br>SMT: We can provide single-sided and double-sided surface mount PCB assemblies in different specifications. <br> <br>Plated Through Hole: We offer plated through hole assembly with selective soldering. <br> <br>[a]https%3A%2F%2Fwww.hitechpcba.com%2Fpcb-assembly[/a]
