This single-display module is suitable for use in Automobile products.
The LCD adopts one backlight with 128 High brightness white LEDs.
Construction: 23.6 lcd ,White LED backlight.

General Specifications of 23.6 Inch 1920x1080 FHD 30PIN LVDS-Double IPS 600nits
No. Item Specification
1 LCD size 23.6 inch
2 Resolution 1920 (RGB)X1080
3 Display mode Normally Black
4 Pixel pitch 0.2715(W) x 0.2715(H) mm
5 Active area 521.28 (W)X293.22 (H) mm
6 Module size 544.8(W)X320.5(H)X9.45(D) mm
7 Pixel arrangement RGB-vertical stripe
8 Interface LVDS
9 Backlight power consumption 23.04 w
10 Panel power consumption TBD
11 Weight 511.6 g (Typ);  529.5 g (Max)
Outline Dimension of 23.6 Inch 1920x1080 FHD 30PIN LVDS-Double IPS 600nits
