PVC Wall Panel Extrusion Line
JWELL Machinery specializes in complete solutions for various PVC wall panel extrusion lines, from plant planing to final profiles. This high-speed PVC wall panel extrusion line is equipped with a specially designed conical twin screw extruder, which makes itself more suitable for producing various types of PVC wall panels and ceiling panels. Our PVC wall panel-making machine has outstanding features of large capacity, high machine quality, easy operation and sustainable service.

The full PVC wall panel extrusion line based on famous brand PLC control system includes mixer, feeding unit, twin screw plastic extruder, mold, calibration unit, haul off unit, cutting unit, film covering unit, stacker, crusher and pulverizer. Before shipment, each PVC wall panel extrusion machine will undergo strict testing and qualified commissioning.

PVC Wall Panel Extrusion Machine Advantages
01.
Our PVC wall panel extrusion line has high output, stable production, and long service time. Reliable and long-term after-sales services are also provided by Jwell.

02.
Special screw structure highly improves the feeding and stable output.

03.
Jwell Machinery has our own screw company founded in 1978 for independent research. As a leading plastic extruder machine factory, we have developed various screws to meet different production requirements, also can ensure sustainable after-sales service.

04.
Our PVC wall panel extrusion machines have optimized temperature and vacuum control systems for better performance.

05.
Easy operation, reduce the technical requirements of the operation of workers and save the workshop space effectively.

PVC Wall Panel Extrusion Machine Specification

High speed main technical parameter of pvc wall panel extrusion line
Type YF240 YF240 YF240A
Max. width of product (mm) 240 240 150*2
Extruder model SJP75/28 SJP93/30 SJP110/28
Max.extrusion capacity (kg/h) 150-250 250-400 400-500
Extruder power (kW) 45 55 90
Cooling water (m3/h) 7 8 10
Compressed air (m3/min) 0.6 0.6 0.8

Classic type main technical parameter of pvc wall panel extrusion line
Type YF108 YF240 YF240A YF300 YF400
Max. width of product (mm) 108 240 150*2 300 400
Extruder model SJZ55/110 SJZ65/132 SJZ65/132 SJZ65/132 SJZ80/156
Max.extrusion capacity (kg/h) 150 250 250 250 450
Extruder power (kW) 22 37 37 37 55
Cooling water (m3/h) 7 8 8 8 10
Compressed air (m3/min) 0.6 0.6 0.8 0.6 0.6

PVC Wall Panel Extrusion Production Line Features
Extruder
High-performance twin screw extruder with famous brand motor, imported inverter.

Famous brand PLC control system allows our PVC wall panel making machines to have easy operation and high automation.

The gearbox adopts an integrated structure, which not only optimizes the structure and weight but also ensures reliable strength.

Calibration Unit
Stainless steel machine frame gives our PVC wall panel extrusion machines a long service life.

Could be moved by motor or by hand.

Equipped with an independent operation panel.


Haul Off
Two tractors driven by two motors.

Speed controlled by imported inverter.

Cutter
Cutting knife movement and saw working controlled by pneumatic cylinder and PLC program system.

Manual cutting and automatic cutting choice.

Fast cutting, flat section.

PVC Wall Panel Making Machine Application
Jwell Machinery PVC wall panel production machine is able to produce various panels, such as hollow wall panels, flat wall panels, fluted panels, rough surface panels and so on. PVC wall panels from our plastic board-making machine are widely used in house building decorative material with advantages like environment-friendly, heat insulation, heat preservation, fireproof, sound insulation, fashionable, and easy to assemble.

As one of extrusion machine manufacturers in china, we can provide kinds of related products for sale, if you have needs, please contact us.
