#chafer #fabric
Chafer Fabrics are the special industrial fabrics mainly made of Nylon 6, Nylon 66 and Polyester yarns. Chafer fabric has quite high breaking strength and good adhesion. Yusheng produces a variety of chafer fabrics, Standard products mainly made of Nylon 6, Nylon 66 and Polyester.

Specification of Chafer Fabric
Nylon6 monofilament nylon chafer fabric：
NO. ITEM Unit Dipped nylon6 monofilament chafer
Warp Weft
1 Material /　 Nylon 6 monofilament Nylon 6 monofilament
2 Structure D 420 420
3 Ave breaking strength N 320N/15 400N/19
4 Breaking Elongation % 26±6 35±6
5 Hot air shrinkage 150C×30min % 3 3
6 Adhension N/2.5cm 200
7 Thickness mm 0.52±0.05
8 Dip pick up % 3
9 Water content % 1
10 Width tolerance mm ±20

Nylon6 multifilament chafer fabric:
NO. ITEM Unit 840D/1* 1260D/1* 1260D/1*
840D/1 1260D/1 840D/1
1 Warp break strength Kg/end ≥60 ≥90 ≥90
Weft break strength ≥60 ≥90 ≥60
2 Warp break elongation % 20±5 20±5 20±5
Weft break elongation % 36±10 36±10 36±10
3 adhesion N/25mm ≥196 ≥196 ≥196
4 Contain water % ≤1.0 ≤1.0 ≤1.0
5 Pick up % 8±3 8±3 8±3
6 Hot air shrinkage 150℃×30＇ % ≤3.0 ≤3.0 ≤3.0
7 thickness mm 0.55±0.07 0.75±0.07 0.65±0.07
8 Warp density End/5cm 26±2 38±2 31±2
9 Weft density End/5cm 32±2 31±2 32±2
