EX02403-A01 2.47 Inch Circular LCD Panel/Screen/Display is a color active matrix TFT-LCD Panel using amorphous silicon TFT's (Thin Film Transistors) as an active switching devices. This model is composed of a TFT-LCD Panel, a driving circuit and a back light system. It is a transmissive type display operating in the normal black. This TFT-LCD has a 2.47 inch diagonally measured active area with resolutions 480 horizontal by 480 vertical pixel array. Each pixel is divided into Red, Green, Blue dots which are arranged in 2 domain stripe and this panel can display 16.7M colors.It is Suitable for vehicle mounted, handheld terminal, industrial LCD, etc.

General Specifications of 2.47 Inch 480x480 Round 35PIN MIPI 400nits-1
No. Item Specification
1 LCD size 2.47 inch
2 Resolution 480x480
3 Active area 62.64×62.64(circle)mm
4 Module size 69.19(H)×71.74(V)×2.45(D) mm
5 Interface MIPI
6 Brightness 400cd/m2
7 Contrast Ratio 1000:1
8 Driver IC HX8379-C
9 Polarizer Transmissive
10 Display Colors 16.7M
11 Viewing Direction All
12 Weight 25g (Max)

Outline Dimension of 2.47 Inch 480x480 Round 35PIN MIPI 400nits-1
