Type1 Portable EV Charging Cable
The cable conforms to the SAE Standard (USA) of EV Charging, which suits electric vehicles manufactured in America. As mostly customer had asked, it has a unique design that one button attached with a hole (reserved for the electronic lock to avoid stealing) on the top of the connector. It consists of Control Box and USA Plug at the tail end, a nice solution for charging.

Features of Jayuan Type 1 Portable EV Charging Cable
Matching SAE J1772-2012.

Ergonomic design.

Convenient connector.

Advanced craft shows a nice appearance.

Longer lifespan and better bending thanks to XLPO & TPU material.

The control box of these Type-1 electric charging cables is adjustable to 10A/13A/16A.

Special internal waterproof protection.

Specifications of Specifications of Jayuan Type 1 Portable EV Charging Cable
Electrical Environment Materials Mechanical
Insulation Resistance: >1000MΩ (DC500V) Operating Temperature: -30℃~50℃ Shell (Thermoplastic): UL94-VO Life: no-load plug>10000times
Flame Retardent
Pins Temperature Rise: <50K Waterproof IP Grade: IP55 / / External Force: 1meters Drop and 2tons vehicle run over pressure affordable.
Withstand Voltage: 2500V / / / / Insertion Force: <100N
Contact Impedance: 0.5mΩMax / / / / / /

If you are looking for a reliable solar products supplier, please choose us, and will be your best partner.
